EMISAR D4V2 *CUSTOM BUILT-TO-ORDER*

Please be noted that the boost driver version will have 40% less output on turbo than the regular version, it is a more efficient driver (90-95%) with longer running time and less heat.

Emisar D4V2 puts a high lumen output but generates a lot of heat at the same time, please acknowledge before purchasing. Unprotected, flat top battery works only (not included in the price), D4V2 does not work with protected battery.

PLEASE READ BELOW BEFORE PURCHASING!

THESE ARE "CUSTOM" BUILT-TO-ORDER SO THESE WILL SHIP ACCORDINGLY!

USER INTERFACE:

ANDURIL 2 UI

DRIVER:

9A LINEAR + FET (DEFAULT & DEPENDS ON THE EMITTER)

12V 2A BOOST AVAILABLE

EMITTERS (LED):

NEW FF EMITTERS

FFL351A & FF351RD

NICHIA 519A

NICHIA 219B

NICHIA 219C

SST20

SST20 4000K (FA4 BIN)

OSRAM + COLORS

CREE XPE (NO BOOST DRIVER AVAILABLE)

NOTE: SST10 5W UV OPTION IS A MULE WITH NO OPTICS + AUXILIARIES ONLY GLASS

BODY COLOR:

BLACK

GRAY

SAND

CYAN (OLDER STOCK PRESSED SWITCH RING)

GREEN

STONEWHITE (OLDER STOCK PRESSED SWITCH RING)

NOTE: SOME ARE OLDER STOCK WITH THE PRESSED SWITCH RING

LIGHT SWITCH:

ALL COLORS + RGB

INCLUDEDS OPTIONS:

STAINLESS BEZEL

DEEP CARRY POCKET CLIP

MAGNETIC CAP

LANDYARD

EXTRA ORING

ANDURIL 2 PRINTED INSTRUCTIONS

24/7 TECH SUPPORT :)

OPTIONAL COPPER OR BRASS BEZEL/SWITCH RING >>> Emisar Noctigon Replacement Bezels – JLHawaii808

NOTE: BRASS SWITCH RING ONLY AVAILABLE ON OLDER GEN HOSTS NOT THE THREDED SWITCH RING PLEASE CONTACT ME ON WHATS AVAILABLE!



Features:

• CNC machined from aircraft-grade aluminum

• Efficient UK made Carclo Quad LED optics

• Unihead construction

• High lumen output and low moon output

• Ramping interface

• Electronic soft touch switch

• Beryllium-Copper springs with 45% IACS superior to stainless steel alloys used for springs with only 2% IACS.

• Temperature step-down

• Waterproof and dustproof to IP67 standard (up to 1 meter)

• Default 18650 body with optional 18500 or 18350 battery tube

• Dimensions: 95mm(length) * 28mm(head) * 24mm(body), 80mm(lenght 18500), 65mm(lenght 18350)



OTF lumen output at start-up:

FFL351A 5000K: 4100LM (TKLAMP TEST)

Nichia 519A : 3800lm

Nichia E21A : 1200lm

SST-20 6500K/5000K: 4200lm

SST-20 4000K/2700K 95CRI: 3000lm



This product uses free software of Anduril 2, distributed under the terms of the GPLv3.

Source code is available from http://tiny.cc/TKAnduril
