Emisar

Emisar D1 Mini Thrower Luminus SBT90.2

Emisar D1 Mini Thrower Luminus SBT90.2

Regular price $97.88 USD
Regular price $99.99 USD Sale price $97.88 USD
Sale Sold out
Shipping calculated at checkout.
BODY COLOR
EMITTER OPTION

LUXWAD EMISAR D1 REVIEW >>> (163) Emisar D1V2 - Best Mini Thrower? - YouTube

Emisar D1 is back!

WARNING! "DO NOT" REMOVE BEZEL/OPTICS OR YOU WILL DAMAGE THE SBT90.2 EMITTER BOND WIRES! WARRANTY VOIDED IF REMOVED YOU ARE RESPONSIBLE FOR A NEW EMITTER WHICH IS $50!



DRIVER:

9A + FET (DT8 DRIVER)

USER INTERFACE:

ANDURIL 2 UI

EMITTER OPTIONS:

LUMINIUS SBT90.2 @ 4500 LUMENS

OSRAM W1 AND W2 (SEE OTHER LISTING)

OSRAM W1 AND W2 COLORS (SEE OTHER LISTING)

LUMINUS SFT40 6500K (SEE OTHER LISTING)

REFLECTOR:

SMOOTH (SAME AS KR1)

OP (ORANGE PEEL) ON FC-40, B35AM AND 519A EMITTERS

BODY COLORS:

BLACK

GRAY

SAND

CYAN

INCLUDED OPTIONS:

STAINLESS BEZEL

NEW! LIGHTED SWITCH (RGB)

CLIP

MAGNETIC CAP

Unprotected, high drain batteries only, protected cells won't work

The magnet is the stronger version by default.



Features:

• CNC machined from aircraft-grade aluminum

• Smooth aluminum reflector

• Unihead construction

• High lumen output and low moon output

• Ramping interface

• Electronic soft touch switch

• Beryllium-Copper springs with 45% IACS superior to stainless steel alloys used for springs with only 2% IACS.

• Temperature step-down • Waterproof and dustproof to IP67 standard (up to 1 meter)

• Default 18650 body with optional 18500 or 18350 battery tube

• Weight: 89g

• Dimensions: 109mm(length) * 35mm(head) * 24mm(body)

W1 (Osram CSLNM1.TG): 900lm, Lux : 110Kcd (110,000cd)

W2 (Osram CSLPM1.TG): 1300lm, Lux: 100Kcd (100,000cd)

XP-L HI 6500K/5000K/4000K: 1300lm, Lux: 45Kcd (45,000cd)

SST-40 5000K/6500K: 2200lm, Lux: 29Kcd (29,000cd)

SFT-40 6500K: 1600lm, Lux: 100Kcd (100,000cd)

FC-40: 1600lm, Lux: 14Kcd (14,000cd)

519A dedomed: 1200lm, Lux: 20Kcd (20,000cd)

SBT90.2: 4000lm, Lux: 100Kcd (100,000cd)

B35AM: 1000lm, Lux: 12Kcd (12,000cd)

This product uses free software of Anduril 2, distributed under the terms of the GPLv3.
