EMISAR D4K TITANIUM
CUSTOM BUILT-TO-ORDER WILL SHIP ACCORDINGLY!
The boost driver upgrade is available for the SST-20, Osram W1/W2, Nichia 219B R9080, as well as 519A version, each LED receives 2A current. The driver is not compatible with Nichia E21A, Nichia E17A, and mule versions of the flashlight.
Please be noted that the boost driver version will have 40% less output on turbo than the regular version, it is a more efficient driver (90-95%) with longer running time and less heat.
(288) Emisar D4K - The D4V2 Killer? - YouTube
(288) 21700 Anduril Quads - Compared! [D4K, PL09, TS25] - YouTube
https://tgreviews.com/2023/04/05/emisar-d4k/
Emisar D4K puts a high lumen output but generates a lot of heat at the same time, please acknowledge before purchasing. Unprotected 21700 flat top battery only (not included in the price), D4K does not work with protected battery.
NEW! ZHU HYBIRD MULE OPTICS >>> ZHU Hybrid Mule Optic – JLHawaii808
BODY:
TITANIUM RAW
TITANIUM STONEWASHED ($5 ADDITIONAL)
USER INTERFACE:
ANDURIL 2 UI
DRIVER:
9A LINEAR + FET
12A LINEAR NO FET (E21A MULE ONLY)
12V 2A BOOST DRIVER OPTION AVAILABLE (NOT AVAILABLE FOR MULES & 5050SMD)
NEW! LUME X1 12V 3A BOOST DRIVER AVAILABLE NOW! (NOT AVAILABLE FOR MULES & 5050SMD)
EMITTER OPTIONS:
FFL351A & FFL351RD
FFL505A (5050SMD)
NICHIA 219B, 219C AND 519A
NICHIA E21A
LUMINUS SST20
LUMINUS SST10 5W 365NM UV LED
LUMINUS SFT40 (5050SMD)
CREE XPE COLORS
MULES:
3MM ALUMINUM MULE SPACER
NO OPTICS & AUXILIARIES
8 X EMITTERS 3535SMD LEDS
16 X EMITTERS E21A LEDS
2-CHANNEL D4K MULE LINK HERE >>>
LIGHTED SWITCH COLORS:
WARM WHITE
COOL WHITE
CYAN
BLUE
AMBER
GREEN
RED
RGB
INCLUDED OPTIONS:
DEEP CARRY POCKET CLIP
MAGNETIC CAP OPTION
LANDYARD
EXTRA ORINGS
BATTERY:
21700 FLAT TOP UNPROTECTED CELL (NOT INCLUDED)
Features:
• CNC machined from Titanium & copper
• Efficient UK made Carclo Quad LED optics
• Unihead construction
• High lumen output and low moon output
• Ramping interface
• Electronic soft touch switch
• Beryllium-Copper springs with 45% IACS superior to stainless steel alloys used for springs with only 2% IACS.
• Temperature step-down
• Waterproof and dustproof to IP67 standard (up to 1 meter)
• Weight:108g
• Dimensions: 103mm(length) * 28mm(head) * 26.5mm(body)
OTF lumen output at start-up:
E21A: 1200lm
519A: 3800lm
SST-20 6500K: 4200lm2
SST-20 5000K: 4200lm
SST-20 4000K/3000K 95CRI: 3000lm
Osram W2: 5000+ Lumens
LUME X1 12V 3A: SFT-25R G1 bin 3800lm 50kcd @ 450m
LUME X1 12V 3A: FFL351A 4000k 2600lm @ 18kcd 260m
This product uses free software of Anduril 2, distributed under the terms of the GPLv3.
Source code is available from http://tiny.cc/TKAnduril
